Long-Range UHF Cattle Ear Tag UHF302
Long-Range UHF Animal Tracking Tag UHF302
High-Performance UHF Electronic Ear Tag Engineered for reliable animal tracking and management, this RFID ear tag combines high durability with advanced RFID technology.
-
Premium TPU Material: Eco-friendly, non-toxic, and resistant to extreme temperatures, hydrolysis, and microbial corrosion.
-
Superior Durability: Crafted with a two-shot injection molding process for reliable waterproof performance and exceptional retention rate.
-
Easy & Secure Application: Features a high-quality copper alloy pin for smooth, secure penetration in harsh environments and thick-furred livestock.
-
Advanced RFID Tracking: Embedded with an ISO 18000-6C / EPC compliant UHF chip for fast, reliable data reading and writing.
-
Versatile Applications: Ideal for livestock breeding, insurance tracking, and slaughterhouse management.
| Parameter | Description |
| Chip | Impinj M730 |
| Raw Materials | Thermoplastic Polyurethane（TPU） |
| Standard | ISO 18000-6C |
| Operating Frequency | 860MHZ-960MHZ |
| Memory Capacity | EPC＞96bit |
| Data Retention | ＞10 years |
| Write Cycles | ＞100,000 times |
| Reading Sensitivity | -10dBm～-75dbm |
| Reading Distance | 0-5meters（depending on reader power, antenna size, and environment） |
| Tag Encapsulation | Two-shot injection molding |
| Dimensions | Cattle Ear Tag:
Panel: Paddle-shaped, 45 * 28 mm or 115 * 75 mm (with embedded chip), Stub: Round, Diameter: 30 mm, Height: 23 mm
Sheep Ear Tag: Panel: Semi-curved rectangular, 45*17mm, Height: 23 mm(with embedded chip), Stub: Round, Diameter: 30 mm, Height: 23 mm
Pig Ear Tag: Panel: Round, Diameter: 30 mm(with embedded chip), Stub: Round, Diameter: 30 mm, Height: 23 mm |
| Color | Yellow(customizable) |
| Tensile Strength | ＞260 N |
| Operating Temperature | -30℃ to 50℃ |
| Humidity | 5%RH – 95%RH |
| Laser Marking | Numbers, QR codes and logos customizable |
